Semi-Auto .multi core strip crimp machine

Short Description:

SA-SH1010 is sheathed cable strip crimp terminal machine ,It’s stripping and crimp terminal at one time , Just change the crimping mold for different terminal ,This machine have automatic straighter inner core function ,It’s very convenient for multi core crimping , For example, crimp 4 core sheathed wire, Directly setting 4 on display ,Then put wire on machine , Machine will autoamtic straighter ,stripping and crimping 4 times on at time , and It’s Greatly Improved wire crimping speed and save labor cost.

Send email to us

Product Detail

Product Tags

Product Video

Product Introduction

SA-AH1010 is sheathed cable strip crimp terminal machine ,It’s stripping and crimp terminal at one time , Just change the crimping mold for different terminal ,This machine have automatic straighter inner core function ,It’s very convenient for multi core crimping , For example, crimp 4 core sheathed wire, Directly setting 4 on display ,Then put wire on machine , Machine will autoamtic straighter ,stripping and crimping 4 times on at time , and It’s Greatly Improved wire crimping speed and save labor cost.

Advantage

1. Design for multi core sheather cable , Stripping crimping multi core at one time , save labor cost .
2. Adopt advanced frequency conversion technology control, energy saving and environmental protection.
3. Strong Stripping power, High-speed and accurate positioning.
4. Suitable for Different various terminals, Adopt high-precision OPT mold, Better crimping effect
5. Easy operate English Touch Display,Convenient for customers operate.

Products Parameter

Model	SA-SH1010
Cable type	Multiple conductor cable, flat cable etc.
Cable outer diameter	1.3 - 32 mm (0.052 - 1.259 inches) (larger cable can be customized)
Conductor size	30 - 16 AWG
Conductor number	2 - 20 (depending on the cable type)
Stripping length	Depending on conductor size
Crimping force	2.0 T
Applicator	OTP
Productivity	3600 pcs./h (depending on the wire type)
Power supply	110, 220 V (50 - 60 Hz)
Power	750 W
Dimension (L * W * H)	800 * 600 * 1250 mm (31.50 * 23.62 * 49.21 inches)
Net weight	145 kg (319.67 lb)
